Application: for charging 12V100AV / 12V140AV / 12V190AV li-ion battery
Protection: IP65 waterproof
Safety of use: no risk of overcharging, protected against reverse polarity
Quick charging: full charging within 3-4 hours (12V100 AV), 5-6 hours (12V140 AV), 7-8 hours (12V190 AV)MAIN FEATURES
COMPACT & LIGHTWEIGHT: the charger weighs just 4.5 kg.- HIGH EASE OF USE: lightweight and compact, quick recharge
COMPACT & LIGHTWEIGHT: the charger weighs just 4.5 kg.
HIGH EASE OF USE: lightweight and compact, quick recharge- RELIABLE: built-in protection: no risk for overcharging. Charger switches off automatically when the battery is fully charged. Protected against reverse polarity.
- WARRANTY: two years.
RELIABLE: built-in protection: no risk for overcharging. Charger switches off automatically when the battery is fully charged. Protected against reverse polarity.
WARRANTY: two years.IMPORTANT INFO
PLEASE REVIEW THE BELOW INFORMATION BEFORE COMPLETING YOUR ORDER
The Rebelcell 12.6V35A battery charger is only intended for use with the 12V100 AV / 12V140 AV / 12V190 AV li-ion batteries. Read the safety warnings and instructions on the charger before use.
DETAILS & SPECIFICATION
TECHNICAL SPECIFICATIONS
CERTIFICATION AND WARRANTY | Automatic charger with advanced high frequency switch mode power supply technology |
Efficiency | >91% |
Size (in mm) | 280 x 176 x 87 |
Weight | 3.5kg |
Weight package | 3.8 kg |
AC input | 230 Volt 50-60Hz |
Power | 1200W |
Charging voltage | 12.6V |
Maximum charge current | 35A |
Charging profile | Pre-charge/CC/CV/Cut-off |
Connector | M8 tongue connector |
Charge status indicator | Yes, via LED |
Minimal battery voltage | 3V |
Works at temperature | -10°c to +40°c |
COMPATIBLE WITH | CHARGING TIME |
12V100 AV Battery | 3-4 h. |
12V140 AV Battery | 5-6 h. |
12V190 AV Battery | 7-8 h. |
ELECTRONICS AND CHARGING INDICATOR
LED 1 | Red <80% |
| Yellow >80% |
| Green 100% |
Over charge protection | Yes |
Reverse polarity protection | Yes |
Short circuit protection | Yes |
Overvoltage protection | Yes |
High temperature protection | Yes |
Cooling | Yes, forced ventilation with fan to cool charger |
Heat sink | Yes, the outside case of the charger functions as heat sink |
