CARACTERISTICI PRINCIPALE
Compact & lightweight: the battery weighs 12.7 kg and is up to 100% more compact than an equivalent (3 x 12V130Ah) lead-battery pack. Saves up to 100 kg in battery weight.- High Ease of Use: can be recharged quickly and in between charges (full recharge within 5–6 h with 42V20A charger).
- BT-App: app to view charge status, current, estimated runtime, charge cycles, temperature, battery health.
Compact & lightweight: the battery weighs 12.7 kg and is up to 100% more compact than an equivalent (3 x 12V130Ah) lead-battery pack. Saves up to 100 kg in battery weight.
High Ease of Use: can be recharged quickly and in between charges (full recharge within 5–6 h with 42V20A charger).
BT-App: app to view charge status, current, estimated runtime, charge cycles, temperature, battery health.- Top performance: deep discharge (up to 100%) and continuous high thrust without negative effects on performance or cycle life.
- Reliable and long life: built-in abuse protection (against deep discharge, over voltage, high temperatures etc.) through BMS and service life up to 10 years.
- Warranty: three years.
Top performance: deep discharge (up to 100%) and continuous high thrust without negative effects on performance or cycle life.
Reliable and long life: built-in abuse protection (against deep discharge, over voltage, high temperatures etc.) through BMS and service life up to 10 years.
Warranty: three years.INFORMAȚII IMPORTANTE
PLEASE REVIEW THE BELOW INFORMATION BEFORE COMPLETING YOUR ORDER
- Use: never use crocodile clamps to connect equipment to the battery. These connections are unsafe and can cause overheating, damaging your equipment or battery. Always use a fuse between the battery and trolling motor, and connect using thick battery cables with M8 tongue connectors and ANEN plug connectors for a secure connection.
- Cha: only charge with a lithium-ion charger that has a CC/CV charge profile (42V max 35A) or charge by your outboard in combination with the Range Extender.
- Wat: the battery is IP67 waterproof. However, do not let the battery sit in water. Secure it in place with fixation bands on a vibration-free surface to prevent sliding.
DETALII ȘI SPECIFICAȚII
TECHNICAL SPECIFICATIONS
| Chemistry | Lithium |
| Voltage | 37.0V |
| Capacity (C1-C20) | 75Ah |
| EqPb (comparable lead battery) | Up to 3 x 12V130Ah |
| Self discharge | 2–4% per month |
| Nominal energy | 2.775 kWh |
| Energy density | 218 Wh/kg |
| Maximum continuous discharge | 100A |
| Peak discharge (10 sec) | 200A |
| Lifetime (#charges) (@ 80% DoD) | 1500 |
| Lifetime (#charges) (@ 100% DoD) | 1000 |
| Dimensions (in mm) | 327 x 173 x 225 |
| Weight | 12.7 kg |
| Weight package | 13.0 kg |
| Connectors | M8 |
| Suitable chargers | 42V20A Lithium charger waterproof: 5–6 h. |
ELECTRONICS & BMS
| Bandwidth voltage | 30V – 42V |
| Charge temperature | 0°C – 45°C |
| Discharge temperature | -20°C – 60°C |
| Storage temperature | 0°C – 45°C |
| Charging profile | CC/CV |
| State of charge indicator | Yes, via BT app |
| Charging via alternator | Yes, via the Range Extender 42V5A |
| Maximum charging current | 35A |
| Charging voltage | 42V |
| Parallel connection | Yes, max 2 batteries (2P) |
| Series connection | No |
| Cell balancing | Yes |
| High temperature protection | Yes |
| Low temperature protection | Yes |
| Frost control | Yes |
| Maximum discharge current protection | Yes |
| Overvoltage protection | Yes |
| Undervoltage protection | Yes |
| Reverse polarity protection | Yes |
| Short circuit protection | Yes |
| Bluetooth app | Yes, for charge status, estimated runtime, current, temperature, cycle life. |
PROTECTION & CERTIFICATION
| Security class (IEC 529) | IP67 |
| Certification | CE, UN38.3, MSDS |
| Shipping classification | UN3480, lithium-ion batteries, class 9 |
| Warranty | Three years |
| Barcode | 8720964631554 |
| EAN | 8720964631554 |
| Product code | 36075REUABT |
| HS code (International / EU) | 850760 / 85076000 |
| ADR | Yes, UN3480 |
