FEATURES
- Body hoist The winch body, as well as all fastening brackets, are made of strong stainless steel.
- Winch mechanism (for lifting and resetting the armature) Winch mechanism consists of: the engine with a closed gear mechanisms and mechanical drive for moving the coil along the shaft. All the mechanical parts involved in the work of the winch lubricated with special waterproof grease.
- Electrical The electrical part of the winch motor is used with an operating voltage of 12 V. On the cover is not installed latching three positional, waterproof button. The set comes winch wire to connect to the battery length of 5 meters and thermal safety switch.
- Cover winches Winch cover is made of durable UV-resistant plastic ABC. On the cover is a winch winch control button.
- Roller The winch rods are made of solid stainless steel 3 mm thick. The rollers are equipped with a rolling roller made of durable plastic.
- Anchor rope The winch is equipped with a nylon rope length of 40 m, with a tensile strength of 360 kg.
- Fasteners The winches are supplied with fixing bolts and nuts made of stainless steel for fixing the winch and roulette body.
- Warranty sheet The product comes with a warranty sheet, with a term of 1 year warranty.
- Packaging Winch is packaged in a sturdy cardboard shipping.
For correct and durable work of the winch, we recommend using STRONGER anchors!
Anchor winch includes a roller and the winch itself. Using the anchor winch is prohibited without regular roller!
SPECIFICATION
| Parameter | Value |
|---|---|
| Maximum anchor weight * | 15 kg |
| Boat length, up to | 7 m |
| Anchor rope | ∅ 4 mm, length 40 m |
| Guide roller | Yes |
| Control knob | Yes |
| Control knob intention | Hoisting / descent |
| A rod for safe anchor transportation | Yes |
| The function of a smooth entry of the anchor into the water | No |
| Free fall anchor | Yes |
| Anchor hoisting speed | 30 m/min |
| Pcs. number in a package | 1 piece |
| Weight | 9 kg |
| Package dimensions (L×W×H) | 377 × 307 × 177 mm |
| Winch dimensions (L×W×H) | 280.5 × 280.5 × 151 mm |
| Guide roller dimensions (L×W×H) | 260 × 82 × 129 mm |
| Model Number | SH – 35S |
| Warranty | 1 year |
| Max. Working load | 90 kg |
