FEATURES
- Winch body The winch body is made of durable 3 mm thick steel.
- Winch mechanism The winch mechanism consists of a closed-type gear, a free-fall mechanism, and a spool for the anchor rope.
- Electrical part The electrical part of the winch consists of a motor with an operating voltage of 12 V. The activation button for the winch is located on the cover. The kit is equipped with a 5-meter long cable for connecting the winch to the battery and a thermal safety relay.
- Pulley The pulley arm is made of 3 mm thick steel. A durable plastic pulley is installed at the end.
- Anchor rope The winch is equipped with a nylon rope with a diameter of 3.5 mm and a length of 30 m, with a maximum load capacity of 360 kg.
- Mounting system The winch is equipped with all necessary fasteners for mounting the body and pulley on the boat.
- Warranty The product has a warranty period of 1 year.
- Packaging The winch and mounting kit for the inflatable boat are packed in a durable transport box.
For correct and durable operation of the winch, we recommend using anchors from the STRONGER company!
The anchor winch includes the pulley arm and the winch itself. Using the anchor winch without the pulley arm is prohibited and voids the warranty.
SPECIFICATION
| Parameter | Value |
|---|---|
| Maximum anchor weight | 8 kg |
| Boat length | up to 4 m |
| Anchor rope | 3.5 mm x 30 m |
| Pulley arm | yes |
| Control button | yes |
| Control button function | raise / lower |
| Safety rod for transport | yes |
| Smooth anchor entry function | no |
| Free-fall anchor function | yes |
| Anchor lifting speed | 20 m / min |
| Weight | 9 kg |
| Package dimensions (LxWxH) | 377 × 307 × 177 mm |
| Winch dimensions (LxWxH) | 250.5 x 260.5 x 130 mm |
| Pulley arm dimensions (LxWxH) | 260 x 82 x 129 mm |
| Boat mounting bracket dimensions (LxWxH) | 408 x 160 x 50 mm |
| Model number | SH – 20 |
| Warranty | 1 year |
| Maximum working load | 90 kg |
