MAIN FEATURES
Versatility: power supply for 12V trolling engines, depth sounder; service battery for angling boat, sailing yacht, motorboat or campervan. - Compact & lightweight: the battery weighs just 13.5 kg and is up to 70% smaller than an equivalent lead-battery, and fits in nearly all boat compartments.
- Parallel / Series connection: can connect up to 4 batteries in parallel (4P) or 2 batteries in series (2P) for additional capacity or higher voltage.
- App: to view charge status, estimated runtime, current, charge cycles, temperature, battery health.
Versatility: power supply for 12V trolling engines, depth sounder; service battery for angling boat, sailing yacht, motorboat or campervan.
Compact & lightweight: the battery weighs just 13.5 kg and is up to 70% smaller than an equivalent lead-battery, and fits in nearly all boat compartments.
Parallel / Series connection: can connect up to 4 batteries in parallel (4P) or 2 batteries in series (2P) for additional capacity or higher voltage.
App: to view charge status, estimated runtime, current, charge cycles, temperature, battery health.- Top performance: deep discharge (up to 100%) without negative effects on performance or cycle life.
- High Ease of Use: compatible with all 12V trolling engines and depth sounders. Easy monitoring of charge status, remaining runtime, battery health, and performance via the Rebelcell App.
- Reliable and long life: built-in abuse protection through BMS and service life up to 10 years. IP66 waterproof.
- Warranty: three years.
Top performance: deep discharge (up to 100%) without negative effects on performance or cycle life.
High Ease of Use: compatible with all 12V trolling engines and depth sounders. Easy monitoring of charge status, remaining runtime, battery health, and performance via the Rebelcell App.
Reliable and long life: built-in abuse protection through BMS and service life up to 10 years. IP66 waterproof.
Warranty: three years.IMPORTANT INFO
PLEASE REVIEW THE BELOW INFORMATION BEFORE COMPLETING YOUR ORDER
- Only charge with recommended lithium (LiFePO4) battery charger with CC/CV charging profile and 14.6V max 75A voltage. Using an unsuitable charger can be unsafe and will automatically void warranty.
- Securely tighten the battery bolts with a socket wrench: improperly fixed terminals can be dangerous and generate heat, which can lead to irreversible damage to your outboard, 12V equipment and battery!
- Always use a suitable fuse between the battery and your equipment to protect both.
- Always use batteries of the same brand, voltage, capacity, age and charge status when connecting in series or parallel. Use cables of same length and of sufficient thickness to connect batteries together and connect tightly with a socket wrench. Fully charge batteries before connecting together. Failure to do so may void your warranty.
- Consult an electrician if you need assistance in connecting or installing your batteries.
- Your battery is ‘waterproof’ according to the IP66 standard. To avoid issues, we recommend placing the battery in a waterproof battery container and/or on a elevation to ensure that the battery is never partly or fully in the water on the bottom of your boat.
DETAILS & SPECIFICATION
TECHNICAL SPECIFICATIONS
| Chemistry | LiFePO4 |
| Voltage nominal | 12.8V |
| Capacity (C1-C20) | 150Ah |
| EqPb (comparable lead battery) | Up to 12V300 Ah |
| Self discharge | 2–4% per month |
| Nominal energy | 1,92 kWh |
| Energy density | 142 Wh/kg |
| Maximum continuous discharge | 200A |
| Peak discharge (<5s) | 400A |
| Parallel / series connection | Parallel: Yes, max 4 batteries (4P) Series: Yes, max 2 batteries (2S) |
| Lifetime (#charges) (@ 80% DoD) | 7500 |
| Lifetime (#charges) (@ 100% DoD) | 5000 |
| Dimensions (in mm) | 330 x 175 x 214 |
| Weight | 13.5 kg |
| Weight package | 14.1 kg |
| Suitable chargers | 14.6V 20A LiFePO4 charger (normal or waterproof) 14.6V 35A LiFePO4 charger waterproof |
| Charging time | 9–10 h (20A charger) 6–7 h (35A charger) |
ELECTRONICS & BMS
| Bandwidth voltage | 10.8V – 14.6V |
| Charge temperature | 0°C – 45°C |
| Discharge temperature | -20°C – 60°C |
| Storage temperature | 0°C – 45°C |
| Charging profile | CC/CV |
| Charging voltage | 14.6V ± 0.2V |
| Charging via alternator | Yes, DC DC converter recommended |
| Maximum charging current | 75A (charger) |
| State of charge indicator | Yes, via Rebelcell BT app |
| Integrated cell balancing | Yes |
| High temperature protection | Yes |
| Low temperature protection | Yes |
| Maximum discharge current protection | Yes |
| Overvoltage protection | Yes |
| Undervoltage protection | Yes |
| Short circuit protection | Yes |
| Bluetooth app | Yes, for charge status, estimated runtime, current, temperature, cycle life. |
| Frost control | No |
PROTECTION & CERTIFICATION
| Security class (IEC 529) | IP66 |
| Certification | CE, MSDS, FCC, RohS, UN38.3 |
| Shipping classification | UN3480, lithium-ion batteries, class 9 |
| Warranty | 3 years |
| Barcode | 8720964631424 |
| EAN | 8720964631424 |
| Product code | 12150RCEDGE |
| HS code (International / EU) | 850760 / 85076000 |
| ADR | Yes, UN3480 |
