CARACTERISTICI PRINCIPALE
Versatility: power supply for 36V and 24V/36V trolling engines; connect in parallel or series to increase your range or voltage.- Compact: the battery weighs 29.0 kg and is up to 70% smaller than an equivalent lead-battery.
- Parallel / Series connection: can connect up to 4 batteries in parallel – to quadruple your capacity for a 36V420Ah power source, or 2 in series – to create a 72V105Ah power source for a 72V electric engine.
- App: to view charge status, estimated runtime, current, charge cycles, temperature, battery health and more.
Versatility: power supply for 36V and 24V/36V trolling engines; connect in parallel or series to increase your range or voltage.
Compact: the battery weighs 29.0 kg and is up to 70% smaller than an equivalent lead-battery.
Parallel / Series connection: can connect up to 4 batteries in parallel – to quadruple your capacity for a 36V420Ah power source, or 2 in series – to create a 72V105Ah power source for a 72V electric engine.
App: to view charge status, estimated runtime, current, charge cycles, temperature, battery health and more.- Top performance: deep discharge (up to 100%) without negative effects on performance or cycle life.
- High Ease of Use: compatible with all 36V trolling engines. Easy monitoring of charge status, estimated runtime, battery health, and performance via the Rebelcell App.
- Reliable and long life: built-in abuse protection through BMS and service life up to 10 years. IP66 waterproof.
- Warranty: three years.
Top performance: deep discharge (up to 100%) without negative effects on performance or cycle life.
High Ease of Use: compatible with all 36V trolling engines. Easy monitoring of charge status, estimated runtime, battery health, and performance via the Rebelcell App.
Reliable and long life: built-in abuse protection through BMS and service life up to 10 years. IP66 waterproof.
Warranty: three years.INFORMAȚII IMPORTANTE
PLEASE REVIEW THE BELOW INFORMATION BEFORE COMPLETING YOUR ORDER
- Only use battery chargers designed to charge 36VLiFePO4 batteries (charging profile: 43.8V CC/CV). Using non-compatible chargers may damage the battery and void the warranty.
- Securely tighten the battery bolts with a socket wrench: improperly fixed terminals can be dangerous and generate heat, which can lead to irreversible damage to your electric outboard, equipment and battery!
- Always use a suitable fuse between the battery and your equipment to protect both.
- Always use batteries of the same brand, voltage, capacity, age and charge status when connecting in series or parallel. Use cables of same length and of sufficient thickness to connect batteries together and connect tightly with a socket wrench. Fully charge batteries before connecting together. Failure to do so may void your warranty.
- Consult an electrician if you need assistance in connecting or installing your batteries.
- Your battery is ‘waterproof’ according to the IP66 standard. To avoid issues, we recommend placing the battery in a waterproof battery container and/or on a elevation to ensure that the battery is never partly or fully in the water on the bottom of your boat.
DETALII ȘI SPECIFICAȚII
TECHNICAL SPECIFICATIONS
| Chemistry | LiFePO4 |
| Voltage nominal | 38.4V |
| Capacity (C1-C20) | 105Ah |
| EqPb (comparable lead battery) | Up to 36V200 Ah |
| Self discharge | 2–4% per month |
| Nominal energy | 4.03 kWh |
| Energy density | 139 Wh/kg |
| Maximum continuous discharge | 100A |
| Peak discharge (<5s) | 200A |
| Parallel / series connection | Parallel: Yes, max 4 batteries (4P) Series: Yes, max 2 batteries (2S) |
| Lifetime (#charges) (@ 80% DoD) | 7500 |
| Lifetime (#charges) (@ 100% DoD) | 5000 |
| Dimensions (in mm) | 522 x 270 x 220 |
| Weight | 29.0 kg |
| Weight package | 29.8 kg |
| Suitable chargers | 43.8V 20A LiFePO4 charger (waterproof): 6–7 h. |
ELECTRONICS & BMS
| Bandwidth voltage | 30.0V – 43.8V |
| Charge temperature | 0°C – 45°C |
| Discharge temperature | -20°C – 60°C |
| Storage temperature | 0°C – 45°C |
| Charging profile | CC/CV |
| Charging voltage | 43.8V ± 0.2V |
| Charging via alternator | Yes, Range Extender or DC DC converter recommended |
| Maximum charging current | 50A (charger) |
| State of charge indicator | Yes, via Rebelcell BT app |
| Integrated cell balancing | Yes |
| High temperature protection | Yes |
| Maximum discharge current protection | Yes |
| Overvoltage protection | Yes |
| Undervoltage protection | Yes |
| Short circuit protection | Yes |
| Bluetooth app | Yes, for charge status, estimated runtime, current, temperature, cycle life. |
| Frost control | No |
PROTECTION & CERTIFICATION
| Security class (IEC 529) | IP66 |
| Certification | CE, MSDS, RohS, UN38.3 |
| Shipping classification | UN3480, lithium-ion batteries, class 9 |
| Warranty | 3 years |
| Barcode | 8720964631226 |
| EAN | 8720964631226 |
| Product code | 36105RCEDGE |
| HS code (International / EU) | 850760 / 85076000 |
| ADR | Yes, UN3480 |
